Data sheet

Stratum C Series

For critical customer applications requiring precise and repeatable depth filtration, the Graver Stratum C series melt blown filters deliver exceptional performance.

With a multi- zoned construction, true clarifying filtration is achieved with no unloading of captured contaminant.

  •  Multi-zone melt blown depth Filter with a true graded pore structure

  •  Thermally bonded Fibers for high void volume and long on-stream life

  •  Available in precise 90% removal effiencies from 0.5 to 75 microns

  •  100% pure virgin polypropylene

  •  Molded center core for higher temperature and pressure capability

  •  Free of surfactants, binders and adhesives

  • Media: Polypropylene

  • End caps/Center Core: Polypropylene

  • Gaskets/O-Rings: Buna-N, EPDM, Santoprene, Silicone, Teflon

                                           Encapsulated Viton (O-Rings only), Viton

  • Micron rating: 0.5, 1, 3, 5, 10, 20, 50, 75 µm

  • Nominal lengths: 5", 9.75", 10", 19.5", 20", 29.25", 30", 39", 40" (12.7, 24.8, 25.4, 49.5, 50.8, 74.3, 76.2, 99.1, 101.6 cm)
