This range of lightweight, intrinsically safe probes has been designed with high weather resistance to cope with the harsh environmental conditions encountered at sea and on land in the oil, gas and petrochemical industries.
DB5 can also be used in the mining industry.
The unit is available in 2 models: 12V and 24V
4 Use zone 0, zone 1 and zone 2.
Certified temperature: -20ºC to + 55ºC.
Volume control as standard
Up to 103 dB (A).
26 different sound outputs, selectable by the user through internal switches
Encapsulated electronics
Second tone selectable using the third wire.
|
Material: |
ABDOS. (Acrylonitrile butadiene styrene). |
|
Finish: |
Available in red as standard. |
|
Sound output: |
100 ± 3dB (A) for the 12V and 24V versions. Typical maximum value only - variable with tone. The tones are in accordance with BS 5839 part 1. |
|
Power consumption: |
Model 24V - 14 mA max. nominal. Model 12V - 12 mA max. nominal. |
|
Certified temperature: |
–20ºC to +55ºC. |
|
Weight: |
0.3kg. |
