Display reads oxygen from 0.05ppm up to 25.0% with no range changes
Analog output can be configured to operate over any of ten ranges from 0-10ppm to 0-25% for best resolution
Field selectable analog output - 1-5V or 4-20mA, isolated.
Complete sample system built in to AMI’s patented cell block.
Very rapid response time from air to low ppm levels.
Easily replaceable sensor, no tools required.
T-2 sensor resistant to 10ppm H2S standard. Optional T-4 resistant to 500ppm H2S.
Simple, versatile installation.
Operates off 10-28VDC with very low power consumption
Analog output can be easily calibrated to a SCADA system or flow computer.
USB connectivity to a PC: Allows complete access to the internal functions and settings.
ModBus: Industry standard protocol over RS485.
Oxygen Sensor life indication with calibration history.
10 user selectable output ranges to choose from.*
High resolution 3 digit LCD.
RFI protected.
1-5VDC and 4-20mA. isolated analog output signals.
USB virtual comport and Modbus Bidirectional RS485 communication for advanced features.*
Datalog – 10 days oxygen reading recording at 1 minute per sample*
Calibration history – stores the last five calibrations with time, date, span factor and calibration gas.*
Brown-out history – stores the last five brown-outs and recoveries.*
Power up history – stores the last ten times the unit was powered up.*
Advanced analog output calibration.*
(* Requires User Interface Software)
Power requirements: 10-28VDC.
Low minimum detection limit.
Excellent repeatability.
Fast upscale/downscale response times.
Patented Cellblock Technology: Integrates all components such as: flow control valve, flow meter, 3-way calibration valve, Sample/Span/Off and compression fittings to be an integral part of the cellblock, eliminating tubing and fittings.
The cell block also provides a compact size, fast response time and front panel sensor access without the need for tools.
Area Classification: Designed to meet requirements for Class 1, Div. 2, Groups C,D application.
Unaffected by changes in flow rate from 0.1 to 2.0 SCFH
Wall mount or 2.0” pipe with standard pipe clamp.
Compact size.
2 year warranty for analyzer, parts and labor.
6 month sensor warranty, life expectancy 1-2 years.
10 user selectable output ranges to choose from: 0-10ppm, 0-50ppm, 0-100ppm, 0-500ppm, 0-1000ppm,0-.500%, 0-1%, 0-5%, 0-10% and 0-25%. The selection of an output range simultaneously controls the datalog so that both functions operate on the same range
Digital display: 3 digit LCD. Reads full scale from 0.05ppm to 25.0% independently of output range selection
Isolated analog output signal: 1-5VDC or 4-20mA represents the output range selected
Power requirements: 10-28VDC <50mA. @ 12VDC
Minimum detection: 50ppb of oxygen
Repeatability: +/- 1% of range or +/- 0.2ppm of oxygen, whichever is greater
Operating temperature range: 25 to 115˚ F
Diurnal temperature specification: < +/- 3 % of scale over temperature range
90% upscale response times: 10ppm – 25% <10 seconds; 0-10ppm < 25 seconds
Typical downscale response: 1 minute exposure to air down to 10ppm: < 15 minutes
Area Classification: Designed to meet requirements for Class 1, Div. 2, Groups C,D applications
Inlet gas pressure: 0.5 to 150psig
Gas connections: ¼” 316 S.S. compression fittings.
Wetted parts: 316 S.S. fittings, electroless nickel plated cellblock, gold plated contacts, acrylic flow meter and Viton O-rings
Unaffected by changes in flow rate from 0.1 to 2.0 SCFH
Mounting: Wall mount or 2.0” pipe
Dimensions: 7.0”W x 6.5”H x 4.5”D
Weight: 6 lbs.
