Display reads oxygen from 0.05ppm up to 25.0% with no range changes
Analog output and alarms can be configured to operate over any of ten ranges from 0-10ppm to 0-25% for best resolution
Analog output 4-20mA, isolated.
Complete sample system built in to AMI’s patented cell block.
Very rapid response time from air to low ppm levels.
Easily replaceable sensor, no tools required.
T-2 sensor resistant to 10ppm H2S standard.
Simple, versatile installation.
Operates off 10-28VDC with very low power consumption
AC-DC converter provided
2 independent, fully adjustable alarm settings with relay contacts.
Oxygen Sensor life indication.
Trace oxygen measurement from 0.05ppm to 25%.
Unaffected by sample flow rate changes between 0.1 – 5 SCFH.
Standard AMI T-2 trace electrochemical sensor.
Panel mount.
Compact size.
10 user selectable output ranges.
3 ½ digit LCD.
2 fully adjustable oxygen concentration alarms• RFI protected.
Isolated 4-20mA. analog output signal.
Power requirements: 10-28VDC <3 watts, supplied with a 115VAC to 12VDC adapter.
Low original cost and virtually maintenance free over its entire life.
Area Classification: Designed to meet General Purpose requirements.
2 year warranty for analyzer, parts and labor.
6 month sensor warranty.
2001LC Series Standard ranges:
0 – 10 ppm, 0 – 50ppm, 0 –100 ppm, 0 – 500 ppm, 0 – 1000ppm, 0 – 5000 ppm, 0 – 1%, 0 – 5%, 0 – 10%, 0 –25%
Sensitivity: 0.5% of full scale
Repeatability: +/- 1% of full scale at constant temperature
Operating temperature: 41°F to 113°F
Humidity: < 95%, non-condensing
Maximum inlet pressure: 100psig.
Operational conditions: Pollution degree 2, Installation category I I.
Drift: +/- 1% of full scale in 4 weeks at constant temperature (dependent on sensor)
Expected cell life: 9 months to 2 years.
Response times:
90% of full scale in less than:
0 – 10 ppm 25 sec
0 – 100 ppm 10 sec
0 – 1000 ppm 10 sec
Output: 4-20mA isolated.
Alarm contacts: 230/117VAC @ 5A, or 28VDC @ 5A, resistive
Power requirements: 24VDC <10W.
Absolute Maximum Power voltage 28VDC
Overall dimensions: 9” w x 5” h x 3” d
Weight 5 lbs
